Atomstack R30 V2 Upgraded Infrared Laser Module 1064nm Laser for Engraving Metal and Plastic
Atomstack
● Metal Rust Removal
● Born for Metal & Plastic Engraving
● High Compatibility: Adaptable to most of the engraving machines, such as Atomstack, Ortur, NEJE, Two-Trees, etc.
30-Day Returns: Protect your shopping experience
12-Month Warranty: Perfect after-sales service
Features:
- The world's first: Atomstack is the first to launch an industrial-grade 1064nm infrared laser module with a repetition rate of 20,000Hz, which is suitable for fast and fine metal engraving, as well as non-metallic materials such as varnished wood furniture, ABS, and plastic.
- Greatly improve work efficiency: After industrial design, the net weight of the module is only 520g (the first generation and other products in the industry are 800g+). Movement speed and work efficiency can be increased by 40% under the same framework
- Born for metal and plastic engraving: Infrared fiber laser has incomparable advantages in engraving metal and plastic surfaces. This is not possible with conventional diode blue lasers.
- Better engraving effect: thanks to the Atomstack spot compression technology, the spot of the R30 V2 laser module is compressed into a circular laser spot with a diameter of 0.03mm. This makes it ideal for engraving on custom jewelry or metal. The engraving effect on the surface of the object is finer, clearer, and less prone to oxidation.
- Rust removal: The 1064nm wavelength laser has excellent absorption ability to the metal surface coating, and can remove rust on a small area of rusty metal without chemical reaction or secondary electrolysis.
- High adaptability: R30 V2 laser module can be adapted to most Atomstack models, including:
- A30 Pro, X30 Pro, S30 Pro
- A20 Pro, X20 Pro, S20 Pro, A20
- A10 Pro, X7 Pro, S10 Pro, X7
- A5 Pro, A5 Pro+
- A5 M30, A5 M40, A5 M50
- A5 20W, A5 10W
- P9 M50, P9 M40, P7 M40, P7 M30
- If you have other brands of engraving machines, such as Ortur, NEJE, Two-Trees, etc., you can also install our Atomstack R30 V2 laser module, and an adapter is included in the box.
- Safety laser: Compared with blue laser, infrared laser has its own safety characteristics. The non-focused light is cold light, which will not cause burns if touched accidentally.
- Long life: 1064nm laser light is stable, with a long service life of 100,000 hours (there will be a certain power attenuation after long-term use)
Laser module Specification:
Brand |
Atomstack |
Model |
R30 V2 |
Optical Output Power |
2W |
Product Material |
Aluminum 6061 Anode |
Circuit Board Size |
44*52mm |
Laser wavelength |
1064nm |
Circuit Board |
V/PWM Modulation Board |
Wire Rod |
22# 2P2.54 Terminal Reverse Wire 80mm |
Optical Lens |
φ6/glass |
Laser Beam Mode |
Spot |
Working Mode |
Pulse Work |
Lightspot Size |
Φ0.03mm |
Working Time |
100000H |
Working Temperature |
0℃~70℃ |
Storage Temperature |
一40℃~85℃ |
Light Temperature |
Non-focal temperature: room temperature |
Product Net Weight |
520g |
Package Included:
1 x |
R30 V2 Laser Module |
1 x |
PCB Circuit Board |
1 x |
Connect board(Other brands series use different adapter boards, please pay attention to the distinction) |
1 x |
Slider |
2 x |
Handle |
1 x |
Fixed Focus Plate |
2 x |
Connection cable |
3 x |
Wrench |
25 x |
Screws |
1 x |
12V 9A Power Supply |
1 x |
Installation Manual |
CAUTIONS:
- The laser light emitted by the laser module is likely to injure persons'eye, so do not directly gaze its end surface and wear appropriate safety glasses to prevent laser light when it is working.
- Laser module needs an appropriate laser driver(PCB). When the laser module connects with power supply, please set the output voltage to zero. The adjustment of the current should be slowly increased or decrease to avoid damaging the device.
- Keep the device working or storing in a dry environment. The anti-dust grade is over one million, in order to prevent dust inside the lens to affect the laser dot shape.
- Working at high temperatures will increase the threshold current, reduce conversion efficiency and speed up the aging of the device.
- When output power is higher than it's specific parameter of operation, it will accelerate the aging of the device.
- When the operation temperature of the laser diode is over 70degree, please do well heat dissipation of it.
- This laser module is an electrostatic sensitive device. Please make sure ground yourself or wear an antistatic wrist strap before you take it.
FAQ:
Q: Is the Atomstack R30 V2 suitable for engraving on curved surfaces?
A: Yes, the R30 V2 can engrave on curved surfaces with its high-speed scanning system, allowing for precise and detailed engravings.
Q: Can the Atomstack R30 V2 engrave on glass?
A: The R30 V2 is primarily designed for engraving on metal and plastic materials. While it may be possible to engrave on glass, it is recommended to consult the manufacturer or conduct tests for optimal results.
Q: How long does it take to learn how to use the Atomstack R30 V2 effectively?
A: The learning curve for using the R30 V2 is relatively short, thanks to its user-friendly interface and intuitive controls. With some practice and experimentation, users can quickly become proficient in operating the R30 V2 and achieving desired engraving results.
Q: Can the Atomstack R30 V2 be used for industrial applications?
A: Absolutely! The R30 V2 is suitable for various industrial applications, including metalworking, plastic manufacturing, and product labeling. Its precision and speed make it a valuable tool for industries that require accurate and efficient engraving.
Q: Does the Atomstack R30 V2 require any specific software to operate?
A: The R30 V2 is compatible with a wide range of software, including popular design programs and engraving software. It supports file formats such as SVG, DXF, and BMP, allowing users to import and engrave their desired designs easily.
Q: Can the Atomstack R30 V2 be used for cutting materials?
A: The R30 V2 is primarily designed for engraving and marking purposes. While it may be capable of cutting thin materials, it is recommended to use a dedicated laser cutting machine for more precise and efficient cutting applications.
Q: What safety precautions should I take when using the Atomstack R30 V2?
A: When using the R30 V2, it is essential to wear appropriate protective eyewear to shield your eyes from the laser beam. Additionally, ensure that the workspace is well-ventilated and follow all safety guidelines provided by the manufacturer to prevent accidents and minimize potential hazards.
Q: Can the Atomstack R30 V2 be used with a rotary attachment for engraving cylindrical objects?
A: Yes, with the use of a rotary attachment, the R30 V2 can engrave cylindrical objects, such as bottles and cups. The rotary attachment allows for 360-degree rotation, enabling precise engraving on curved surfaces.
LaserGRBL VS LightBurn Software
LaserGRBL (Free) (Windows): LaserGRBL Download Page
LaserGRBL is one of the best Windows software for image Laser Engraving. It is able to load any image, pictures and logo and send to your laser engrave with few click. It is specifically developed for use with hobbist laser cutter and engraver and could be a good free and easy alternative to picengrave, benbox, T2laser, lightburn for who don’t need more then a simple and effective tool. LaserGRBL is compatible with any engraver based on Grbl v0.9 and Grbl v1.1 standards.
LightBurn (Paid - 30 Day Free Trial) (Windows/Mac OS/Linux): LightBurn Download Page , Purchase LightBurn software key.
LightBurn is layout, editing, and control software for your laser cutter. With LightBurn you can:
- Import artwork in a variety of common vector graphic and image formats (including AI, PDF, SVG, DXF, PLT, PNG, JPG, GIF, BMP)
- Arrange, edit, and even create new vector shapes within the editor, with powerful features like offsetting, boolean operations, welding, and node editing
- Apply settings like power, speed, number of passes, cut order, brightness & contrast, dithering mode, and much more
- Send the result directly to your laser cutter
LightBurn is a native application written for Windows, Mac OS, and Linux.
